SQ3427EEV
www.vishay.com
THERMAL RATINGS (T A = 25 °C, unless otherwise noted)
I DM Limited
10
Limited by
R DS(on) *
1
0.1
T C = 25 °C
100 μs
1 ms
10 ms
100 ms
1 s, 10 s, DC
Vishay Siliconix
0.01
Single Pulse
B V DSS Limited
0.01
* V GS
0.1 1 10 100
V DS - Drain-to-Source V oltage ( V )
minimum V GS at w hich R DS(on) is specified
Safe Operating Area
1
Duty Cycle = 0.5
0.2
0.1
0.1
0.05
Notes:
P DM
t 1
t 1
t 2
0.01
0.02
Single Pulse
t 2
1. Duty Cycle, D =
2. Per Unit Base = R thJA = 110 °C/W
3. T JM - T A = P DM Z thJA(t)
4. Surface Mounted
10 -4
10 -3
10 -2
10 -1
1
10
100
1000
Square Wave Pulse Duration (s)
Normalized thermal Transient Impedance, Junction-to-Ambient
S11-2124-Rev. B, 07-Nov-11
5
Document Number: 66826
